Schneider Electric LV516637 EasyPact CVS160F 125A 3P 3D MCCB – 36kA, TM-D Thermal-Magnetic
The Schneider Electric LV516637 EasyPact CVS160F is a 125A 3P 3D MCCB with a TM-D thermal-magnetic trip unit and 36kA breaking capacity at 380/415V AC. It provides adjustable thermal overload and magnetic short-circuit protection for three-phase low-voltage distribution systems.
Description
The Schneider Electric LV516637 EasyPact CVS160F is a 125A 3-pole molded case circuit breaker (MCCB) designed for reliable protection of low-voltage AC electrical distribution systems. It features a 3P 3D configuration and a TM-D thermal-magnetic trip unit, providing thermal overload and magnetic short-circuit protection for distribution applications. Schneider Electric identifies LV516637 as an EasyPact CVS160F circuit breaker with a 36kA breaking capacity at 380/415V AC.
The EasyPact CVS160F 125A MCCB is designed for 50/60Hz AC networks and has a rated current of 125A. The TM-D trip unit combines adjustable thermal overload protection with magnetic short-circuit protection, allowing the breaker to protect feeders and distribution circuits against excessive current and fault conditions.
With a 36kA Icu at 380/415V AC, the LV516637 circuit breaker provides substantial short-circuit interruption capability for commercial and industrial electrical distribution. Schneider Electric documentation also specifies 70kA Icu at 220/240V AC for the F-class CVS160F range. The service breaking capacity is specified according to the applicable operating voltage.
The 3P 3D configuration provides protection across all three poles and is intended for three-phase distribution systems. The breaker uses a fixed mounting configuration with backplate mounting and front connections, making it suitable for installation in distribution boards, switchboards and electrical control panels.
The TM-D thermal-magnetic trip unit provides adjustable long-time thermal protection. For the 125A configuration, the thermal adjustment range is approximately 87.5A to 125A, allowing the protection setting to be matched to the requirements of the connected electrical circuit. Magnetic protection provides short-circuit interruption without requiring a separate electronic trip unit.
The Schneider LV516637 EasyPact CVS160F also provides an 8kV rated impulse withstand voltage, Category A utilisation and compliance with IEC 60947-2. Schneider documentation identifies the device as suitable for installation in Class II insulation switchboards based on its Class II front-face insulation characteristics.
Designed for practical power-distribution applications, the EasyPact CVS160F 125A MCCB combines compact construction, thermal-magnetic protection and high short-circuit performance. It is suitable for industrial feeders, commercial buildings, distribution boards and low-voltage switchboards where dependable 125A circuit protection is required.
| Specification | Details |
|---|---|
| Manufacturer | Schneider Electric |
| Product Range | EasyPact CVS |
| Product Family | EasyPact CVS100...250 |
| Product Type | Molded Case Circuit Breaker (MCCB) |
| Device Short Name | CVS160F |
| Reference | LV516637 |
| Device Application | Distribution |
| Number of Poles | 3P |
| Protected Poles | 3D |
| Rated Current (In) | 125A |
| Rated Current Reference Temperature | 50°C |
| Trip Unit | TM-D |
| Trip Unit Technology | Thermal-Magnetic |
| Trip Unit Rating | 125A |
| Protection Type | Thermal overload + magnetic short-circuit |
| Network Type | AC |
| Rated Frequency | 50/60Hz |
| Breaking Capacity Code | F |
| Icu at 220/240V AC | 70kA |
| Icu at 380/415V AC | 36kA |
| Icu at 440V AC | 36kA |
| Ics at 220/240V AC | 70kA |
| Ics at 380/415V AC | 36kA |
| Ics at 440V AC | 18kA |
| Rated Impulse Withstand Voltage (Uimp) | 8kV |
| Utilisation Category | Category A |
| Thermal Protection Adjustment | 87.5–125A |
| Long-Time Pickup | Adjustable |
| Mounting | Fixed |
| Mounting Support | Backplate |
| Connection | Front |
| Control Type | Toggle |
| Neutral Position | Left |
| Earth-Leakage Protection | Without Vigi add-on |
| Mechanical Durability | 25,000 cycles |
| Electrical Durability | 12,000 cycles at 415V, In |
| Operating Temperature | -25°C to +70°C |
| Storage Temperature | -50°C to +85°C |
| Pollution Degree | 3 |
| Standards | IEC 60947-2 |
| Certifications | IEC, CCC, EAC |
| Front Face Insulation | Class II |
| Approx. Dimensions | 105 × 161 × 86mm |
| Approx. Weight | 1.8kg |
Key Features
- 125A rated current for low-voltage distribution applications.
- 3-pole, 3D MCCB configuration.
- Schneider Electric EasyPact CVS160F platform.
- TM-D thermal-magnetic trip unit.
- Adjustable thermal overload protection.
- Magnetic protection for short-circuit faults.
- 36kA Icu at 380/415V AC.
- 70kA Icu at 220/240V AC.
- 36kA Icu at 440V AC.
- 50/60Hz AC network compatibility.
- 8kV rated impulse withstand voltage.
- Category A utilisation according to IEC 60947-2.
- Fixed backplate mounting.
- Front connection arrangement.
- Toggle-operated manual control.
- 25,000-cycle mechanical durability.
- 12,000-cycle electrical durability at 415V and In.
- Class II front-face insulation capability for suitable switchboards.
- Compatible with the EasyPact CVS accessory platform.
- Suitable for commercial and industrial power distribution.
Applications
- Three-phase power distribution
- Industrial distribution boards
- Commercial electrical distribution
- Low-voltage switchboards
- Main and sub-distribution panels
- Feeder circuit protection
- Industrial control panels
- Building electrical systems
- Machinery power feeders
- Commercial building protection
- Factory electrical distribution
- Overload protection
- Short-circuit protection
- Three-phase AC circuit isolation and protection
